UL94 Flammability Standards: Vertical & Horizontal Burn



UL94 test is a preliminary sign to check the flammability of plastics used in any application. For example, plastic parts used in electronic devices and appliances.

UL94 class:HB、V-0、V-1、V-2、5VA、5VB、VTM-0、VTM-1、VTM-2、HBF、HF-1、HF-2。

HB is horizontal burn

V0,V1,V2,5VA,5VB are vertical burn;

VTM-0,VTM-1,VTM-2 are vertical burn for film materials;

HBF,HF-1,HF-2 is horizontal burn for foamed plastic.



1. Horizontal burnHB

Test method

常用UL94阻燃测试



      Flammability rating UL 94 HB

Test criteria

Burning rate in V

Flammability rating

Test specimen thickness 3-13mm

≤40 mm/min

HB

Test specimen thickness < 3

≤75 mm/min

HB

Flame is extinguished before first mark

≡ 0 mm/min

HB



2. 50w(20mmVertical test(UL 94-V):V-0、V-1或V-2

      Test method

常用UL94阻燃测试

      Flammability rating UL 94 V

Test Criteria

V-0

V-1

V-2

Burning time of each individual test specimen (s)
(after first and second flame applications)

≤10

≤30

≤30

Total burning time (s)
(10 flame applications)

≤50

≤250

≤250

Burning and afterglow times after second flame application (s)

≤30

≤60

≤60

Dripping of burning specimens
(ignition of cotton batting)

no

no

yes

Combustion up to holding clamp
(specimens completely burned)

no

no

no



3. 500w(125mm)Vertical test 5VA or 5VB

Test method

动图封面

Rod test





动图封面

Sheet test



      Flammability rating UL 94 5VA 5VB



Test critieria

5VA

5VB

Burning and afterglow times of specimens after fifth flame application (s)

60s

60s

Dripping of burning specimens

No

No

Hole formation

No

Yes





4. UL 94 VTM Rating: VTM-0, VTM-1 and VTM-2 ‐ Thin Material Vertical Burning Testing




Flammability rating UL 94 VTM

Test Criteria

VTM-0

VTM-1

VTM-2

Burning time of each individual test specimen (s)
(after first and second flame applications)

10s

30s

30s

Total burning time (s)
(10 flame applications)

50s

250s

250s

Burning and afterglow times after second flame application (s)

30s

60S



60s

Dripping of burning specimens
(ignition of cotton batting)

No

No

Yes

Combustion up to holding clamp
(specimens completely burned)

No

No

No



5. UL 94 HBF: HBF, HF-1 and HF-2 ‐ Horizontal Burning Foamed Material

       Flammability rating UL 94 HBF, HF-1, HF-2

This test grants three different types of ratings depending on burning rates and or after flame times. A material will be classified as an HBF material:

if it does not have a burning rate exceeding 40 mm per minute over a 100 mm span or

if it ceases to burn before flaming or glowing reaches the 125 mm mark.

Test criteria (test specimens)

HF-1

HF-2

Burning time (s)

4/5  2s

1/5  10s

4/5  2s

1/5  10s

Burning and afterglow time of each individual specimen (s)

30s

30s

Dripping of burning specimen

(ignition of cotton batting)

No

No

Damaged length of individual specimen (mm)

<60 mm

<60 mm
